ASUS ROG Z11 GAMING BUSINESS PC CASE
ASUS ROG Z11 Mini-ITX/DTX Gaming Case with Patented 11° Tilt Design, Compatible with ATX Power Supply,3-Slot Graphics, Front I/O USB 3.2 Gen 2 Type-C, 2x USB 3.2 Gen 1 Type-A and ARGB Control Button
Case Size
Mini Tower
Motherboard Support
Mini-ITX
Mini-DTX
Drive Bays
4 x 2.5" Bay
1 x 2.5"/3.5" Combo Bay
Expansion Slots
(3 expansion slots space)
Front I/O Port
2 x USB 3.2 Gen1
1 x USB 3.2 Gen2 Type C
2 x USB 2.0
Tempered Glass
Front Side
Right Side
Radiator Support (Rear)
120 mm
240 mm
Cooling Support (Top)
2 x 120 mm
2 x 140 mm
Cooling Support (Rear)
2 x 120 mm
Maximum CPU Cooler Height
130 mm
Maximum GPU Length
320 mm
Maximum PSU Length
160 mm (ATX or SFX)
Removable Dust Filters
Front
Top
Bottom
Maximum Cable Management Space
40 mm
Dimensions
194 (W) x 531 (H) x 386 (D) mm 7.64 (W) x 20.9 (H) x 15.2 (D) inch
Weight
8.73 Kg
AURA Sync
ARGB
EXPERT FEATURES :
Mini-ITX/DTX case: support Mini ITX /DTX motherboards
Premium aesthetics: 4mm tempered-glass panels with sleek aluminum frame and Aura Sync lighting
Patented 11°Tilt design & Optimized airflow & Extra cable routing space: With 11° tilt design, providing an additional 40 mm of space at the back of the motherboard for optimal cooling around CPU, GPU ,the M.2 SSD that can be installed on the back of the motherboard, as well as extra space for easy cable management.
Ready for powerful components: Supports ATX PSU, 3-slot graphics card without a riser cable, up to five fans, 240mm radiator and water-cooling pump and reservoir
Extensive connectivity: A built-in extension hub and rich front panel I/O ports, including USB 3.2 Gen 2 Type-C, two USB 3.2 Gen 1 Type-A and ARGB control button, make connecting components and devices a breeze.
Easy installation and maintenance: Extra cable routing space with multifunction cover, cable strips and removable dust filters offer effortless cable management and maintenance
Dual Orientation for flexibility to fit your workspace
ASUS TUF Gaming GT301 Mid-Tower Compact Case for ATX Motherboards with honeycomb Front Panel, 120mm AURA Addressable RBG fans, headphone hanger, and 360mm radiator support, 2 x USB 3.2
EXPERT FEATURES
Stylishly design: Perforated honeycomb front panel to aid airflow and features a tempered-glass side panel to showcase your build’s internals in the compact case.
Efficient cooling: Equipped with three 120mm Aura Sync addressable RGB-illuminated fans and one 120mm rear fan, plus up to six fan-mounting points for targeted airflow.
Space reserved for 280/360mm water-cooling radiators in front and 120mm at rear
Integrated 6 ports Aura Sync addressable-RGB controller hub and a dedicated front panel control button to create a stunning lighting effect
Extensive storage options: up to 2 HDD (trays included) and 6x SDD (2x dedicated bracket included, one is on the power supply shroud) mounting locations
Combat-ready: Customized headphone hook which can be hanged on both sides
Model
TUF Gaming GT301
Case Size
Mid Tower
Motherboard Support
ATX
Drive Bays
4 x 2.5" Bay
2 x 2.5"/3.5" Combo Bay
Expansion Slots
7
Front I/O Port
1 x Headphone
1 x Microphone
2 x USB 3.1 Gen1
LED Control Button
Reset Button
Segotep, an emerging IT brand, specializes in the DIY "mechatronics" business and actively promotes the development of industry standards. The R&D team has 10 years of experience in R&D and production of switching power supplies. It specializes in DIY power supply products and is determined to inject a strong source of power in the DIY market of the computer to provide high quality and efficient power products for its customers.
Here are more details about Knight01:
We're all about the things that make building a PC such a rewarding experience. The sense of achievement. The joy of making and creating something uniquely yours in form and function and, of course, the thrill of bringing your creation to life without melting your components.
Build From a Different Angle
ATX 24-Pin 90° Adapter, with Added Capacitors for Stable Output
The Cooler Master ATX 24-Pin 90° Adapter improves the connection between your motherboard and PSU. By allowing the main power cable to be installed at a 90° angle, builders no longer need to wrap or fold the cable up and back over the motherboard, thus reducing the amount of cable needed in front of the motherboard tray.
We're all about the things that make building a PC such a rewarding experience. The sense of achievement. The joy of making and creating something uniquely yours in form and function and, of course, the thrill of bringing your creation to life without melting your components.
ARGB GPU Support Bracket
Fortify Your GPU
The ARGB GPU Support Bracket utilizes the strength and aesthetic of tempered glass in completely new ways. The strength of the TG supports the biggest, baddest cards out there. The CNC machining provides edge-lit ARGB. The universal design of the support arm offers hassle-free adjustment, by sliding and locking in place, to fit a high range of graphics card and PC case combinations. If your build is on the subtler side, switch off the lighting for an elegant, invisible GPU support bracket.
Eliminate Graphics Card Sag
Edge-Lit ARGB Tempered Glass
Versatile Support
Multiple Orientations
Easy To Install
Protect Your Components
Versatile Support
The universal design of the support arm offers hassle-free adjustment, by sliding and locking in place.
Multiple Orientations
Includes two supports with different orientations for you to either place it at the tail-end, or the side of the GPU.
Easy To Install
With straightforward adjustment of the support, installation is painless. The solid base is reinforced by a strong magnet to secure it in place.
A crystal-clear tempered glass front panel sports 3 x CF120 ARGB fans
Illumination can be easily assigned via the included ARGB controller (pre-routed to a Reset/ARGB button on the front panel)
IMPRESSIVE CLEARANCES -
The MasterBox 520 interior accommodates E-ATX (up to 12” x 10.7”), ATX, micro-ATX and mini-ITX motherboards
CPU coolers up to 165mm in height
Graphics cards (GFX/GPU) up to 410mm in length
ATX PSUs up to 200mm in length expert zone
MULTIPLE COOLING OPTIONS –
Comes with 3 x CF120 ARGB frontal fans and 1 x MasterFan Lite 120 rear fan; The front and top panels each support up to 3 x 120mm fans/2 x 140mm fans, or a 360mm radiator, the rear panel supports 1 x 120mm fan/radiator
TEMPERED GLASS SIDE PANEL -
Premium systems can be installed, accessed, and showcased through the tempered glass side panel, which can be removed easily without tools (an additional screw can be used to further secure the panel)
RICH CONNECTIVITY I/O PANEL -
The I/O panel features 1 x USB 3.2 Gen 1 Type-A port
1 x USB 3.2 Gen 2 Type-C port expert zone
1 x audio jack and 1 x Reset/ARGB button allowing for streamlined data transmission and unlimited connectivity
EXPERT SPECIFICATIONS
Model Number
MB520-KGNN-S01, MB520-WGNN-S01
Exterior Color
Black, White
Materials - Exterior
Steel, ABS Plastic, Tempered Glass
Materials - Left Side Panel
Tempered Glass
Dimensions (L x W x H)
499 x 210 x 498mm (Incl. Protrusions), 430 x 210 x 479mm (Body Size)
Motherboard Support
Mini ITX, Micro ATX, ATX, SSI CEB, E-ATX*, (*up to 12" x 10.7" motherboards, may impact cable management feature)
Expansion Slots
7
3.5" Drive Bays
2
2.5" Drive Bays
3
I/O Panel
1x USB 3.2 Gen 1 Type-A, 1x USB 3.2 Gen 2 Type-C, 1x 3.5mm Headset Jack (Audio+Mic), 1x Reset/ARGB button expert zone
Included Accessories
ARGB Fans Hub
Pre-installed Fans - Front
3x CF120 ARGB
Pre-installed Fans - Rear
1x MasterFan Lite 120
Fan Support - Top
3x 120mm, 2x 140mm
Fan Support - Front
3x 120mm, 2x 140mm
Fan Support - Rear
1x 120mm
Radiator Support - Top
120mm, 140mm, 240mm, 280mm, 360mm, (recommended maximum thickness -55mm)
A crystal-clear tempered glass front panel sports 3 x CF120 ARGB fans
Illumination can be easily assigned via the included ARGB controller (pre-routed to a Reset/ARGB button on the front panel)
IMPRESSIVE CLEARANCES -
The MasterBox 520 interior accommodates E-ATX (up to 12” x 10.7”), ATX, micro-ATX and mini-ITX motherboards
CPU coolers up to 165mm in height
Graphics cards (GFX/GPU) up to 410mm in length
ATX PSUs up to 200mm in length expert zone
MULTIPLE COOLING OPTIONS –
Comes with 3 x CF120 ARGB frontal fans and 1 x MasterFan Lite 120 rear fan; The front and top panels each support up to 3 x 120mm fans/2 x 140mm fans, or a 360mm radiator, the rear panel supports 1 x 120mm fan/radiator
TEMPERED GLASS SIDE PANEL -
Premium systems can be installed, accessed, and showcased through the tempered glass side panel, which can be removed easily without tools (an additional screw can be used to further secure the panel)
RICH CONNECTIVITY I/O PANEL -
The I/O panel features 1 x USB 3.2 Gen 1 Type-A port
1 x USB 3.2 Gen 2 Type-C port expert zone
1 x audio jack and 1 x Reset/ARGB button allowing for streamlined data transmission and unlimited connectivity
EXPERT SPECIFICATIONS
Model Number
MB520-KGNN-S01, MB520-WGNN-S01
Exterior Color
White
Materials - Exterior
Steel, ABS Plastic, Tempered Glass
Materials - Left Side Panel
Tempered Glass
Dimensions (L x W x H)
499 x 210 x 498mm (Incl. Protrusions), 430 x 210 x 479mm (Body Size)
Motherboard Support
Mini ITX, Micro ATX, ATX, SSI CEB, E-ATX*, (*up to 12" x 10.7" motherboards, may impact cable management feature)
Expansion Slots
7
3.5" Drive Bays
2
2.5" Drive Bays
3
I/O Panel
1x USB 3.2 Gen 1 Type-A, 1x USB 3.2 Gen 2 Type-C, 1x 3.5mm Headset Jack (Audio+Mic), 1x Reset/ARGB button expert zone
Included Accessories
ARGB Fans Hub
Pre-installed Fans - Front
3x CF120 ARGB
Pre-installed Fans - Rear
1x MasterFan Lite 120
Fan Support - Top
3x 120mm, 2x 140mm
Fan Support - Front
3x 120mm, 2x 140mm
Fan Support - Rear
1x 120mm
Radiator Support - Top
120mm, 140mm, 240mm, 280mm, 360mm, (recommended maximum thickness -55mm)
Mesh front panel – offers efficient airflow for demanding systems from the mesh front panel
Aggressive intakes large intakes on each side of the front panel Pay tribute to high Performance Cars
Edge to edge transparent side panel showcase your build through the transparent side panel expert zone
Cooling support Support for a total of six 120mm fans, and front, top and rear radiator placement ensures that you don't have to compromise on performance
Graphics Card support up to 400mm You won't ever have to worry about the fit of your graphics card with support for even the largest, widest cards
MESH FRONT PANEL
The fine mesh front panel filters dust while offering efficient airflow for demanding systems.
EXCELLENT THERMAL PERFORMANCE
Optimized airflow due to the semi-meshed front panel and ventilation holes on top of the case.
FAN AND RADIATOR SUPPORT
Front: Three 120mm or two 140mm* fans and up to a 360mm radiator with a maximum thickness of 50mm without fans.
Top: Two 120mm or two 140mm fans and supports a 120mm or a 240mm radiator.
Rear: One 120mm fan or radiator. All to ensure you don't have to compromise on performance.
* 2 x 140mm fans in front can only be mounted behind the front plate
EDGE-TO-EDGE TRANSPARENT SIDE PANEL
Showcase your build through the transparent side panel.
EXPANDING THE POSSIBILITIES
The spacious interior fits all standard motherboards for your gaming needs.
ATX
MICRO-ATX
MINI-ITX
MAIN COMPONENTS CLEARANCE
The MB511 case supports CPU Coolers up to a height of 165mm, Graphic cards up to a length of 410mm and Power Supplies up to a length of 180mm.
Polygonal Mesh features a 3-dimensional contour and is also capable of simultaneously providing high airflow and dust filtration.
A crystalline tempered glass side panel dons a crystalline design, precision engineered for strength as well as aesthetics
Three included addressable RGB fans flood the build with lighting while providing considerable airflow.
For enthusiast-grade cooling, 2360 millimeter radiators are supported on the top and front panel to keep the most extreme systems cool.
Support for up to 7120 millimeter fans and front, top, and rear liquid cooling ensure the utmost in performance.
From the manufacturer
Make It Yours.
We're all about the things that make building a PC such a rewarding experience. The sense of achievement. The joy of making and creating something uniquely yours in form and function and, of course, the thrill of bringing your creation to life without melting your components.
MasterBox TD500 Mesh
Exquisitely Ruthless
The MasterBox TD500 Mesh E-ATX PC chassis turns high airflow performance into an art form with a geometric, three-dimensional mesh front panel and a tempered glass side panel plausibly cut from crystal ore. Raw performance is powered by three pre-installed ARGB fans mounted in front to light up every intricate angle of its structure.
Polygonal-Mesh
Crystalline Tempered Glass
Triple ARGB Fans
Optimized Airflow
Roomy Interior
Dual 360mm Radiator Support
Crystalline Tempered Glass
The Crystalline aesthetics design spans the edges of the tempered glass interacting with component lighting.
Versatile Cooling Options
Open Airflow design, Fine Mesh front and top panel supporting up to seven 120mm fans and 360mm radiator.
Roomy Interior
The spacious interior fits all standard ATX and Micro-ATX motherboards configuration. Support for up to a 410mm graphics card, a 165mm CPU cooler, and up to a 180mm PSU in length provides room for upgrades.
Product Description
The E-ATX MasterBox TD500 Mesh takes airflow performance and turns it into an art form. Powered by three pre-installed ARGB fans, airflow is fed through a geometric, three-dimensional mesh front panel into a system viewed from a crystal-clear tempered glass side panel. The Crystalline Tempered Glass side panel is precision engineered for both its toughness and its aesthetics through CNC machining. Polygonal Mesh takes its form from Cooler Masters Fine Mesh technology, simultaneously providing high airflow, dust filtration, and a strengthened structure. With advanced technology set firmly into fine art, the MasterBox TD500 Mesh Black carves its own path to the bleeding edge.
Cooler Master MasterCase H500P Mesh ARGBMCM-H500P-MGNN-S11 Black PC Case with Dual 200mm Fans for High-Volume Airflow, Builder-Focused Chassis Panels, Liquid Cooling Ready
DUAL 200MM ARGB FANS – Two massive 200mm MF200R RGB fans draw high-volume airflow into the case for superior cooling (includes an additional 140mm fan at the back) – fully compatible with RGB-certified motherboards (ASUS Aura, Gigabyte Fusion, MSI Mystic Light, and ASRock) for comprehensive ARGB lighting.
BUILDER FOCUSED – A DIY or case modding dream, the front mesh intake panel, transparent top exhaust panel, and both side panels can be easily taken off – perfect for creative people looking to personalise their PC.
TEMPERED GLASS SIDE PANEL – The easy-to-remove light-grey tinted side panel combined with minimalist CPU cut out cover, PSU shroud, and clean cable management covers with dedicated routing creates a minimalist frame in which to showcase the hardware inside. Supports E-ATX* (*12″ x 10.7″ will limit cable management features) , ATX, Micro-ATX, and Mini-ITX motherboards – features 2 additional PCI slots at the rear to better highlight graphics cards.
LIQUID COOLING READY – The H500P accommodates liquid coolers with radiators up to 360mm in length either within the top panel or behind the front mesh.
ACCESSIBLE I/O PANEL – Features 2 x USB 3.2 (formerly USB 3.0) ports, 2 x USB 2.0 ports, 1 x 3.5mm audio jack, 1 x 3.5mm mic jack, ARGB Controller and 1 x 2-to-3 ARGB Splitter
Fully Mesh Front Panel
Dual 200 mm ARGB LED Fans
Cable Management & PSU Cover
Vertical GPU Support
360 mm Liquid Cooling Support
Tempered Glass Side Panel
ARGB Controller and 1-to-3 Splitter Cable Included
ITX, Micro ATX, ATX, SSI CEB, E-ATX*, (*up to 12" x 14.1", may impact cable management and case features, remove cable cover and GPU fan bracket features)
Expansion Slots
7
5.25" Drive Bays
N/A
2.5" / 3.5" Drive Bays (Combo)
2
2.5" Drive Bays
2
I/O Panel
2x USB 3.2 Gen 1 (formerly USB 3.0), 1x USB 3.2 Gen 2 Type-C, 1x single Audio Jack, 1x Reset/ARGB button
ARGB Controller
ARGB Hub
Pre-installed Fans - Front
2x 200mm ARGB Fan
Pre-installed Fans - Rear
1x 120mm SickleFlow PWM ARGB
Pre-installed Fans - Top on HDD cage
1x 120mm SickleFlow PWM (GPU Fan)
Fan Support - Top
3x 120mm, 2x 140mm, 2x 200mm
Fan Support - Front
3x 120mm, 2x 140mm, 2x 200mm, *200mm Mounting Hole Spacing 154 x 154 w/ up to 30mm thickness
Steel: 493mm x 220mm x 506mm (incl. Protrusions), Steel: 482mm x 220mm x 477mm (excl. Protrusions), TG: 493mm x 224mm x 506mm (incl. Protrusions), TG: 482mm x 224mm x 477mm (excl. Protrusions)
Motherboard Support
Mini ITX, Micro ATX, ATX, E-ATX
Expansion Slots
7
5.25" Drive Bays
2
2.5" / 3.5" Drive Bays (Combo)
6 (3x drive cages)
2.5" Drive Bays
8 (2 + 6 combo)
I/O Panel
2x USB 3.0 Type A, 1x USB 3.1 Type-C, 1x 3.5mm Headset Jack (Audio+Mic)
The top and front panel are entirely mesh, featuring the iconic CM690 curve and Cooler Master's signature rhombus pattern. The fine mesh on the CM694 achieves optimal airflow while also filtering out dust with a single layer.
MODULAR DRIVE CAGES
3 Drive Cages can be individually added, removed, or repositioned to make room for longer graphics cards and/or top & front radiators.
GRAPHICS CARD STABILIZER
Graphics cards installed within the case are reinforced by an arm, ensuring the safe delivery and transportation of systems.
RICH CONNECTIVITY (I/O PANEL)
The dust-proof I/O Panel features rubber shields, 2 x USB 3.0 ports, a USB 3.1 (Gen 2) Type-C port, and a 4 pole headset jack.
COOLING SUPPORT
RADIATORS
Top:
120 / 140 / 240 / 280 / 360mm
(mount fans above bracket for maximum compatibility)
Front:
120* / 140* / 240* / 280** / 360mm*
*remove 2 out of 3 drive cage
**remove 2 out of 3 drive cages & ODD
Rear:
120mm
COOLING SUPPORT
FANS
Top:
120mm x 3 / 140mm x 2
Front:
120mm x 3 / 140mm x 2 (without ODD)
120mm x 2 / 140mm x 2 (with ODD)
Rear:
120mm x 1
MOTHERBOARD SUPPORT
Mini-ITX
Micro-ATX
ATX
E-ATX *
*E-ATX up to 12" x 10.7" impacts cable management options
MASSIVE STORAGE SUPPORT
Simultaneous support for 6 x 3.5” HDDs
and 8 x 2.5” SSDs ensure substantial
storage capabilities.
USB 3.0 x 2, USB 2.0 x 2, Mic x 1 / Audio x 1, RGB Control Button
3.5" Drive Bay
2
2.5" Drive Bay
3
Expansion Slots
7
Cooling Fan Support
Front
120mm x 3 (ARGB fans x 3 pre-installed)
Top
120mm x 2
Rear
120mm x 1 (ARGB fan x 1 pre-installed)
Maximun Number of Fans
6 Max.
Water Cooling Support
Front
*240mm / 120mm
Top
*240mm / 120mm (Max. component height on motherboard is 40mm)
Rear
120mm
Max. Graphics Card Length
300 (mm) / 11.8 (in) (Only fans at the front panel)
270 (mm) / 10.6 (in) (Radiator with fans at the front panel)
(Horizontal graphics card slots are compatible with RTX 3080/3070.)
Max. CPU Cooler Height
165 (mm) / 6.5 (in)
Max. PSU length
160 (mm) / 6.3 (in)
Onboard Lighting System
Intergrated Lighting with Addressable RGB LEDs and Dynamic Lighting Effects in the Front Panel
Deepcool CH370 WH Micro- ATX PC Gaming Case - Black . Support- Mini-ITX/Micro-ATX. Pre-Installed 1 x 120 mm Rear Fan - R-CH370-BKNAM1-G-1 . Alloy Steel
Expert Features
Black, Micro ATX, 413×215×431mm (L×W×H)
4 Expansion Slots, 2 x 3.5” Drive Bay, 2+1 x 2.5” Drive Bay
DEEPCOOL CC560 Gaming White ATX Case
DEEPCOOL CC560 White ATX Mid Tower Tempered Glass. Support Mini-ITX / mATX / ATX, 4x Pre installed 120mm LED Fans. CPU Cooler Upto 163mm, GPU Upto 370mm, 360mm Rad Supported, 7X PCI Slot. Front I/O: 2X USB, HD Audio
Expert Features
CC560 WH mid-tower ATX case offers new and experienced builders a perfect start with great component compatibility and high-quality features.
A well-ventilated chassis design with an airflow front panel and a large mesh top panel to ensure fresh air is circulating to cool down system components.
Ensure great cooling ability with four pre-installed 120mm fans with bright LEDs and optimized airflow.
Ample interior space to support multiple liquid cooling radiator configurations with room for 360mm/280mm radiators in front or 240mm on top.
Showcase your system build with a clean and clear full-sized tempered glass side panel window
ASUS ROG Z11 Mini-ITX/DTX Gaming Case with Patented 11° Tilt Design, Compatible with ATX Power Supply,3-Slot Graphics, Front I/O USB 3.2 Gen 2 Type-C, 2x USB 3.2 Gen 1 Type-A and ARGB Control Button
