140mm blue LED fan rated at 1000 RPM and 46.11 CFM for optimum yet silent cooling
Crescent shape with metal mesh panel design provides great air flow and usage comfort
7 degree tilt for easy and wider viewing angle while working or leisure
Premium matte black finish to gel in with every place and situation
Compatible with 15.6" notebooks and below
Design
The Blue Aeolus
Blue & Black Color Mix
The whole body of WIND PAL MINI is in black:
Black metal mesh and black plastic supporting structure.
Along with a blue LED light, this cooler demonstrates the classic match of black and blue.
Slim Design
The crescent shape shows a slim and portable theme of this cooler.
High Quality Metal Mesh
The front panel is made of high quality metal mesh, which allows optimal airflow through the panel to cool the notebook effectively.
Sleek Design
The crescent body and the flat metal mesh form into a perfect piece that consists of beautiful lines.
Cable Management Groove
WIND PAL MINI has a long USB power cable to connect to the notebook; and a carefully designed groove allows you to tidy up the cable when you put this into your bag.
Supporting Feet with Adjustable Angle
The gap between the supporting feet and the cooler base allows you to unfold them easily and provides you the best viewing angle to use your notebook.
Features
14cm Blue LED Fan
WIND PAL MINI has a built-in 14cm fan to provide increased airflow to cool your notebook. With blue LED lights, this fan offers more than just cooling.
Metal Mesh Panel
The front panel is flat in metal mesh and this panel covers the whole part of the hot spots of your notebook. The honeycomb holes allow the cold air to blow the heat away quickly.
7-Degree Angle Brings You Comfortable Viewing
In order to ensure a better experience, WIND PAL MINI adopts 7-degree angle - what the industry recognizes as the most comfortable support angle. It's not only in line with the vast majority of users' viewing habits, but also in line with the spine, offering a more healthy experience.
Performance
Big Airflow for Optimal Cooling
The front panel is flat metal mesh. This panel covers the whole part of the hot spots of your notebook. The honeycomb holes allow the cold air to blow the heat away quickly.
Sleek Design
The crescent body and the flat metal mesh form into a perfect piece that consists of beautiful lines.
As the first member of DeepCool digital CPU air cooler, the newborn AK620 DIGITAL carries everything you love about the classical AK ZERO DARK Series, with the sleek low-profile magnetic status display and ARGB LED strips, let’s play some light not so crazy
DeepCool AK620 DIGITAL features six pieces 6mm all-black heatpipes with raised copper coldplate to maximize heat dissipation to overall 260w TDP which supports even overclocked CPUs for mighty gaming performance. AK620
DIGITAL carries a thermal paste in package, please apply it on after removing the protective film of coldplate
Heatsinks of AK620 DIGITAL CPU air cooler are covered by a digital screen to display the real-time temperature and utilization of system's CPU, number on screen will flash as warning when CPU temp is over 90℃(194℉). The display requires an open USB 2.0 header for data synchronization and is controlled via a simple application which can be downloaded in DeepCool official website
Tired of crazy bling CPU coolers but don’t want the zero-light style? DeepCool AK620 DIGITAL offers a solution in balance. Two slim ARGB LED strips are attached on the digital screen sides, whiches combine the minimalism of AK
ZERO DARK with proper cyber style as the new design language of DeepCool aesthetics
High-speed 1850RPM FK120 120mm FDB fans on AK620 DIGITAL CPU air cooler features 68.99CFM airflow and 2.19mmAq air pressure to build an efficient air cooling system, noise damping pads in fan corners avoid vibration whiches keep noise level under 28dB(A) even in full load, meanwhile, a low noise adaptor is contained in the box for quieter using experience
AK620 DIGITAL CPU air cooler measures 138mm width without blocking most RAM, the fan can be adjusted to proper height if RAM slots are too high to be compatible with; Standing 162mm height is compatible with most ATX/ M-
ATX case, checking CPU cooler height limit of PC case before buying is highly recommended
DeepCool AK620 DIGITAL CPU Air Cooler widely supports Intel LGA 1700/1200/1151/1150/1155/2066/2011-v3/2011 and AMD AM5/AM4 with suitable all-metal brackets in the box
Please leave the protective film over the display in place until the installation of your new cooler is complete; this will ensure that the glassy panel stays as pristine as possible
Expert Specs
Application For Intel : LGA2066/2011-v3/2011/1700/1200/1151/1150/1155
AMD : AM5/AM4
Product Dimensions
129×138×162 mm(L×W×H)
Heatsink Dimensions
127×110×157 mm(L×W×H)
Net Weight
1486 g
Heatpipe
Ø6 mm×6 pcs
Fan Dimensions
120×120×25 mm(L×W×H)
Fan Speed
500~1850 RPM±10%
Fan Airflow
68.99 CFM
Fan Air Pressure
2.19 mmAq
Fan Noise
≤28 dB(A)
Fan Connector
4-pin PWM
Bearing Type
Fluid Dynamic Bearing
Fan Rated Voltage
12 VDC
Fan Rated Current
0.12 A
Fan Power Consumption
1.44 W
LED Type
Addressable RGB LED
LED Connector
3-pin(+5V-D-G) and 9-pin USB 2.0
LED Rated Voltage
5 VDC
LED Power Consumption
4.75 W
EAN
6933412728221
P/N
R-AK620-WHADMN-G
Expert Description
R-AK620-WHADMN-G
Digital White ARGB CPU Air Cooler
DeepCool AK620 Digital White ARGB CPU Air Cooler Mighty 260w TDP 6 Copper Heatpipes Dual-Tower with Status Display Screen and ARGB LED Strips 120mm FDB Fan for LGA 1700 / 1200 / 1151 / 1150 / 1155 / M5 / AM4
Introducing the DeepCool PN650M, your go-to power supply that’s ready to take on the latest Intel ATX 3.1 and PCIe 5.1 standards! Check out these electrifying features:
High-Powered Connectivity: 1 x 12V-2x6 + 5 x EPS/PCIe ports
Future Proofing: Provides 2x total system power for 0.1 ms—no more worries about random power spikes!
Gold Standard Efficiency: 80 Plus Gold certified for amazing efficiency under 80% of typical loads. Also rated Gold by Cybenetics for added peace of mind.
Reliable Power: Features a main Japanese electrolytic capacitor, active PFC, full-bridge SRC LLC, and a DC-to-DC topology for hold-up times of ≥ 16 ms under high loads (80%).
PCI-E 5.1 Ready: Comes with a high-grade 105C-resistant 16AWG copper-core 12V-2x6 cable, providing up to 450W for today’s powerful GPUs.
Stylish Sleeved Cables: Outfitted with sleek sleeved cables straight out of the box for that premium aesthetic and feel.
Dynamic Cooling: Equipped with a 120mm dynamic FDB fan that adjusts its speed based on the PSU's cooling needs—keeping things chill!
Altitude Tested: Built tough, the PN650M can operate at altitudes up to 5000 meters—perfect for gamers at any elevation!
Safety First: Packed with a range of safeguards, including:
OPP (Over Power Protection)
OVP (Over Voltage Protection)
SCP (Short Circuit Protection)
OTP (Over Temp Protection)
OCP (Over Current Protection)
UVP (Under Voltage Protection)
NLO (No Load Operation)
SIP (Surge & Inrush Protection)
Connector Options:
1 x Main Power Connector (20+4)Pin
2 x CPU (4+4)Pin
3 x PCI-E (6+2)Pin
1 x 12V-2x6 (16Pin)
2 x SATA + 1 x 4Pin Peripheral
Get ready to power your gaming adventures with the PN650M—where reliability meets gamer-style performance! 🎮⚡️
A BREATH OF FRESH AIR :The CH360 DIGITAL provides exceptional airflow from all sides of the case; from the high airflow front to the hybrid tempered glass side panel.
HYBRID AIRFLOW GLASS SIDE PANEL : A unique tempered glass and mesh hybrid side panel provides a crystal-clear view into the heart of your system while also supplying modern GPUs with additional ventilation.
REAL-TIME DUAL-STATUS DIGITAL DISPLAY: Choose between CPU and GPU temperatures, utilization, or both (switches between temperature and utilization in 5-second intervals).
MAXIMUM COOLING CAPACITY : The CH360 DIGITAL has a plethora of cooling configurations, from the ability to mount a 360mm radiator in front to the two included 140mm ARGB fans up front—the cooling configurations are endless.
LARGE RANGE OF COMPATIBLE COMPONENTS : With the ability to support 165mm tall CPU coolers, 320mm GPUs, and 160mm PSUs; the CH360 DIGITAL can be configured with a wide range of modern components.
BIGGER, BRIGHTER, BETTER : Two luminous PWM-enabled 140mm ARGB fans come pre-installed on the front and introduce an abundant amount of fresh air into the chassis. A 120mm ARGB fan is included in the rear of the case
STRESS-FREE BUILDING : The magnetic hybrid panel with an optional security screw, magnetic air filters, integrated GPU support arm, a removeable hard drive cage, and 26mm of cable management space behind the motherboard tray.
CONVENIENCE AT ARM'S REACH :Everything necessary for daily routines is within reach with a Type-C, a USB 3.0 port, and a hybrid audio port, all conveniently located on the case I/O panel.
DEEPCOOL MORPHEUS ARGB WHITE CASE
MORPHEUS
Modularity has a new face, and it comes to us in the form of DeepCool’s internally reconfigurable ATX+ chassis: the MORPHEUS. With incomparable compatibility and a spacious layout, the MORPHEUS is the best option for the DIY modder or the casual PC enthusiast.
A NEW TAKE ON MODULARITY
If sticking to the same system layout for years sounds boring, the MORPHEUS is exactly what you are looking for. Easily switch between the classic single chamber configuration and the dual chamber layout with a simple switch of a few parts. Everything necessary to shift between the two configurations is included, as well as a vertical GPU mount.
AIRFLOW AT ANOTHER LEVEL
High airflow panels surround the MORPHEUS case from the front, right, top, bottom, rear, and even the top of the PSU shroud; there will be no shortage of airflow provided to the high-powered heat-generating components inside. High-flow mesh filters are included for the front, top, and bottom panels and will keep dust out.
EXTENSIVE COOLING CAPABILITY
Fan options are unparalleled, with the ability to mount thirteen 120mm or 140mm fans or go to the extreme and add up to six 200mm fans into the conversation. The highly modular fan rails make these configurations a reality.The MORPHEUS can also support up to three 420mm radiators simultaneously. 420mm radiators can be mounted to the front, top, bottom, and side of the motherboard tray.
Bottom:3 x 120/3 x 140/2 x 180/2 x 200mm (Dual Chamber)
PSU Shroud:3 x 120/3 x 140mm (Single Chamber)
Rear:1 x 120/1 x 140mm (Single Chamber)
CPU Coolers
195mm (Single Chamber)
132mm (Dual Chamber)
A TRINITY OF FANS!
A set of highly convenient trinity fans come mounted inside the MORPHEUS: three beautifully bright 140mm ARGB fans are united into a single 420mm unit. The trinity of fans only require the wiring of a single set of PWM and ARGB cables, greatly reducing the amount of cable management.
MAXIMUM COMPATIBILITY
The ATX+ form factor of the MORPHEUS case guarantees compatibility with a large range of components. This ATX+ DeepCool case supports E-ATX motherboards while also having compatibility for GPUs up to 480mm in length, 195mm tall CPU coolers in the single chamber configuration, and multiple 420mm radiators.
DUAL REAL-TIME DIGITAL DISPLAY
Save precious space on your desktop by moving the monitoring of temperatures and usage of your CPU and GPU onto the built-in display that is included with the MORPHEUS case. A simple-to-install app and an open USB 2.0 header will get the dual display up and running.
A BEVY OF I/O PORTS
With four USB 3.0 ports, a Type-C port, and a hybrid audio port, there is no shortage of devices that can be accessed from the top front I/O panel. There is also an LED cycle button to control the built-in ARGB controller, an HDD activity LED, and a Power button to round out the front I/O.
BITS!
Add a bit of a personal touch with the fun rubber square bits! Included as a fun addition, the pixels can be used with majority of the mesh panels of the MORPHEUS case. Leave messages for others, add custom logos, or create your own 8-bit character!
Expert Specifications
Materials ; ABS+SPCC+Tempered Glass
Motherboard Support : Mini-ITX / M-ATX / ATX / E-ATX
Front I/O Ports
USB 3.0 x 4
Audio x 1
Type-C x 1
3.5″ Drive Bays ; 2
2.5″ Drive Bays ; 2 + 1
Expansion Slots ; 9 Slots
Pre-Installed Fans ; Side:1 x 420mm ARGB
Fan Support
Front: 3 x 120 / 3 x 140 / 2 x 180 / 2 x 200mm
Top: 3 x 120 / 3 x 140 / 2 x 180 / 2 x 200mm
Side: 3 x 120 / 3 x 140mm
Bottom: 3 x 120 / 3 x 140 / 2 x 180 / 2 x 200mm
PSU Shrouded: 3 x 120 / 3 x 140mm
Rear: 1 x 120 / 1 x 140mm
Radiator Support
Front: 120/140/240/280/360/420mm
Top: 120/140/240/280/360/420mm
Side: 120/140/240/280/360/420mm
Bottom: 120/140/240/280/360/420mm
Rear: 120/140mm
CPU Cooler Height Limit ; 195/132mm
GPU Length Limit ; 480mm
Power Supply Type ; ATX PS2(maximum length: 180mm)
Product Dimensions ; 528 x 250 x 551 mm (L x W x H)
Built-in four fans provide massive airflow to cool the whole notebook base with no blind area
The creative Multi-Core Control Technology enables users to apply 4 different fan-working statuses: 4 fans on / 2 upper fans on / 2 downside fans on / 4 fans off
Ergonomic design with 2 viewing angles available for the most comfort in use
Massive metal mesh panel for superb cooling performance
2 USB ports allow users to connect their personal USB devices
Sleek Design
The crescent body and the flat metal mesh form into a perfect piece that consists of beautiful lines.
Cable Management Groove
WIND PAL MINI has a long USB power cable to connect to the notebook; and a carefully designed groove allows you to tidy up the cable when you put this into your bag.
Supporting Feet with Adjustable Angle
The gap between the supporting feet and the cooler base allows you to unfold them easily and provides you the best viewing angle to use your notebook.
14cm Blue LED Fan
WIND PAL MINI has a built-in 14cm fan to provide increased airflow to cool your notebook. With blue LED lights, this fan offers more than just cooling.
Metal Mesh Panel
The front panel is flat in metal mesh and this panel covers the whole part of the hot spots of your notebook. The honeycomb holes allow the cold air to blow the heat away quickly.
7-Degree Angle Brings You Comfortable Viewing
In order to ensure a better experience, WIND PAL MINI adopts 7-degree angle - what the industry recognizes as the most comfortable support angle. It's not only in line with the vast majority of users' viewing habits, but also in line with the spine, offering a more healthy experience.
Big Airflow for Optimal Cooling
The front panel is flat metal mesh. This panel covers the whole part of the hot spots of your notebook. The honeycomb holes allow the cold air to blow the heat away quickly.
Sleek Design
The crescent body and the flat metal mesh form into a perfect piece that consists of beautiful lines.
Blue & Black Color Mix
The whole body of WIND PAL MINI is in black:
