Expert Features

• 24 PORT | 24 x GbE PoE+ 300W | 2 x SFP: 24 Gigabit PoE+ ports with 300W total power budget, support up to 32w for one port. 2 Gigabit SFP Port provide flexibility in network access management
• One Key Switch for CCTV and VLAN: CCTV function support remote power and data feeding up to 250m long distance, which is easy to expand network via ethernet cable to somewhere without power supply but need fix device such as IP Cameras. VLAN mode isolate the PoE+ ports from each other, which can improve the network environment and reduces network maintenance costs.
• PD Detect and PD Alive: PoE ports can automatically detect and supply power to IEEE802.3af/at compliant Powered Devices (PD). PD Alive check function (watchdog) supports monitor connected PD (Powered Device) status. If a PD stops working and responding, this PoE switch will reactivate the PD by resuming POE port power. It also support port power supply prioritization, guarantee the continuous power supply of key nodes.
• Desktop and Rackmount Support: 19-inch metal shape supports desktop or rackmount placement, and includes all the necessary mounting hardware in the box.
• High Quality chipset inside: Use High Quality POE chipset to ensure stable operation of the product.Plug & play: Mode A alternative 1/2 (+), 3/6 (-) power supply, simple set up with no software or configuration needed. 19-inch metal shape supports desktop or rackmount placement, and includes all the necessary mounting hardware in the box.

CRS326-24G-2S+RM Features:

• Dual Boot Operating System: Choose between RouterOS for advanced routing and Layer 3 features, or SwOS for a simplified, switch-only OS with enhanced switch-specific features.
• 24 Gigabit Ethernet Ports: High-speed connectivity for all your network devices.
• 2 x SFP+ Ports: Support for both 1.25 Gb SFP and 10 Gb SFP+ modules for high-speed fiber connectivity.
• Advanced Switch Features: Includes port-to-port forwarding, VLAN configuration, MAC filtering, traffic mirroring, and bandwidth limitations.
• Simplified Management: Easily select your operating system from the RouterBOOT loader settings.
• Passive Cooling: Designed with passive cooling for quieter operation.
• Reliable Performance: Provides wire-speed connectivity with advanced features for efficient network management.

CRS326-24G-2S+RM Specifications:

• Product Code: CRS326-24G-2S+RM
• Architecture: ARM 32-bit
• CPU: 98DX3236, 1 core, 800 MHz
• RAM: 512 MB
• Storage: 16 MB FLASH
• Switch Chip Model: 98DX3236
• Dimensions: 443 x 144 x 44 mm (1U rackmount)
• RouterOS License: License 5
• Max Power Consumption: 24 W
• Cooling Type: Passive
• Power Input: 2 DC inputs (DC jack, PoE-IN), 10-30 V
• PoE Input: Passive PoE, 10-30 V
• Ethernet Ports: 24 x 10/100/1000 Gigabit Ethernet
• SFP+ Ports: 2 (Supports both 1.25 Gb and 10 Gb modules)
• Serial Console Port: RJ45
• Certifications: CE, EAC, ROHS
• Operating Temperature: -40°C to 60°C
• MTBF (Mean Time Between Failures): ~200,000 hours at 25°C
• IP Rating: IP20
