| VEIKK , A50 , DRAWING , TABLET , 10 |
{attribute:VEIKK , A50 , DRAWING , TABLET , 10 |
|---|
Additional information
Related products
Euronet UPS Lead Acid Battery 12V 7AH
Euronet UPS Lead Acid Battery 12V 7AH
Expert Features :
- Non-Spillable Sealed Construction
- No Water Topping Required
- Maintenance-Free Operation
- Low Pressure Venting System
- Low Self-Discharge – Long Shelf Life
- Wide Operating Temperature Range
- High Recovery Capability
- High Charge Acceptability
- Ultra Long Life Service
- Low Maintenance
- High Performance
- User Friendly
NCTS UPS ONLINE 1KVA 800 WATT NU1K2
| Online Ups 1KVA / 800W | |||||||
| MODEL | NU1K2 | ||||||
| PICTURE |
|
||||||
| ● Load power factor is 0.8, adaptive for the develplent trend fo electrical ● Equipment and the load capacity is more strong ● Active input power factor correction (PFC), input power factor is over 0.98 ● Wide input voltage and frequency range, adaptive for extreme adverse grid environment of remote areas ● It can be connected with generators ● Zero transfer time effective ensures the safety and reliability of load operation | |||||||
| Specification | Single Phase In & Out | ||||||
| Rated output capacity | 1KVA/800W | ||||||
| Rated | Rated voltage | 220VAC | |||||
| AC input | Input voltage range | 115-300VAC±5 | |||||
| Input frequency range | (45-55)±0.5Hz | ||||||
| bypass voltage | 80VACx(1±5%)-285VACx(1±5%) | ||||||
| Battery Input | battery group voltage | 24V | |||||
| battery method | Internal (7ah x 2pc) | ||||||
| backup time(half/full) | half load≥10 minutes，full load≥5minutes(standard) | ||||||
| maximum input current when power on | <150% of rated current | ||||||
| battery charging time | 5hours can charge to 90%(standard) depend on the capacity of external battery group(long-running) | ||||||
| AC output | Output voltage | 220VAC±1%(invert output) | |||||
| Output frequency | 50±5Hz(when AC input is normal) 50Hz±1% (when ac inout is abnormal ) | ||||||
| wave form | sine wave THD<3%( linear load) sine waveTHD<8%(Nonlinear load) | ||||||
| output power factor | 0.8 | ||||||
| Overload ability | 130% load lasting not less than 30s,Recovery point is 90% load | ||||||
| Output current peak coefficient | 3:01 | ||||||
| Transfer time between AC and Battery | 0ms | ||||||
| Communication and monitoring functions | RS232(can transfer to 485，Dry node，Smart slot(can expand to SNMP,SMS and other monitoring methods) | ||||||
| Tower | N.W(KG) | 8.5 | |||||
| G.W(KG) | 9 | ||||||
| Qty/ carton | 2 | ||||||
| Unit Size(W X H X D)mm | 442*227*330 | ||||||
| Carton Size(W X H X D)mm | 475*455*345 | ||||||
| Business Terms | |||||||
| Production ability | 200 Piece/Pieces per Day | ||||||
| Delivery time | Sample delivery time | ||||||
| Order delivery time | |||||||
| Delivery port | |||||||
| Application area | Widely used in financial, telcom, govenment, traffic, manufacture, education etc. | ||||||
| Certification | ISO9001, ISO14001, CE, ROHS | ||||||
GENERAL UPS Battery 12V 9AH SLA Rechargeable Replacement Battery with T2 Terminal for UPS Back Up , Electric Scooter, Emergency Lighting, Wheel Chair, and More
UPS Battery 12V 9AH ACID Rechargeable
Expert Features
- LONGEVITY --- 12v 7ah 8ah Rechargeable Sealed Lead Acid Replacement Battery. Low self-discharge, up to 600 charging and discharging cycles . High Capacity and efficiency low internal resistance for high discharge current.
- ADVANCED TECHNOLOGY --- Top-Quality materials and careful processing. With 99,9% above-average high purity level and corrosion resistant micro crystal structure. AGM processing technology, Maintenance-free, Leak proof.
- EASY TO INSTALL --- The 12V 9Ah battery is configured with standard F2 Style Terminal. Accumulators in general are fully-charged on delivery.
- WIDE RANGE OF APPLICATIONS --- Emergency power UPS- equipments , Power wheels, Electric scooter, Emergency light, Home alarm equipment, Elevator backup power supply, Kids ride-on toy, Firefighting equipment , Rehab, Small starter batteries and more.
APC Back-UPS 1600VA 230V 900W AVR Uninterruptible Power Supply (UPS) Line-Interactive 1.6 kVA 900 W ; 4 AC Surge-Protected Outlet ; Network Protection | BX1600MI-GR
Expert Features:
- Compact Design: Space-saving form factor ideal for home office and business environments (BX750MI-GR: 160 x 120 x 355 mm).
- Surge Protection: Provides 4 battery backup outlets with surge protection to shield devices from power surges.
- Instant Power Supply: Automatically supplies power during an outage, ensuring continuity for critical devices.
- Automatic Voltage Regulation (AVR): Corrects low or high voltage without using the battery, saving battery life for power outages.
- 1Gb Network Protection: Safeguards connected devices from surges traveling through data lines, preserving internet speed.
- PowerChute Software: Prevents data loss and corruption during extended power outages with PowerChute Personal Edition Software.
- Front Panel LED Indicators: Easily check the status of your UPS with clear LED lights for power and battery health.
Expert Specs:
- Input Voltage: 230V
- Rated Power: 1600 VA / 900 W
- Product Type: Uninterruptible Power Supply (UPS)
- Input Connection: Schuko CEE 7/7P
- Output Connections: 4 Schuko outlets with battery backup and surge protection
- Battery Type: Lead-acid battery
- Battery Voltage: 24 V
- Battery Capacity: 7.0 Ah
- Battery Life: 3-5 years
- Recharge Time: 8 hours
- Run Time: Varies based on load (refer to runtime graph)
- Dimensions: 160 x 120 x 355 mm
- Weight: 9.5 kg
- Included Accessories: User manual, 1.2m cable
UPS BESTONE 1200VA 720WATT
UPS-BESTONE-1200VA
1200VA-720W
Input:
Voltage: 100V / 110V / 120V: 80 ~ 150Vac 220V
Frequency: 50 / 60Hz ± 10% (auto-sense)
Output:
Voltage: 100V / 110V / 120Vac ± 10% or 220V / 230V / 240Vac ± 10%
Frequency: 50 / 60Hz ± 1% (auto-sense)
Waveform: Mains mode: pure sine wave ;
battery mode: simulated sine wave
Crest factor: 3:1
Transfer time: Typical 2 ~ 7 ms; Max.10 ms
