| VEIKK , A50 , DRAWING , TABLET , 10 |
{attribute:VEIKK , A50 , DRAWING , TABLET , 10 |
|---|
TP-Link Archer TX20U Nano AX1800 WiFi 6 Adapter With USB 2.0, Nano Size, MU-MIMO, OFDMA, 1201 Mbps Speed, WPA3 Security, Preloaded Driver – Windows 10/11 Compatible
Additional information
Related products
Netis N3D AC1200 Wireless 300Mbps & 5GHz 867Mbps Dual Band Router
Netis N3D AC1200 Wireless 300Mbps & 5GHz 867Mbps Dual Band Router ,802.11a/b/g/n/ac device supported ,Multiple modes: AP, Repeater, Client FROM EXPERT ZONE
- Works seamlessly with all 802.11a/b/g/n/ac devices
- Simultaneous 2.4GHz 300Mbps and 5GHz 867Mbps connections
- Various WAN connection types in AP Router mode- DHCP, Static IP, PPPoE, L2TP, PPTP, Dual Access (Russia PPPoE/PPTP/L2TP)
- Multiple wireless modes- AP, Client
- Multi-SSID providing up to 6 additional separate networks for guests and friends
- 4* 5dBi high gain antennas
- Easy wireless security setup at a push of the WPS button
- Intelligent bandwidth control to manage the bandwidth usage for each computer reasonably
- Internet Access Control- IP filtering, MAC Filtering, Domain Filtering based on time
- Fast Ethernet ports ensuring high speed connection
- Quick setup, with built-in multilingual management page
Netis N3D Expert Specification FROM EXPERT ZONE
| <span "="">Wireless | |
| Standards | IEEE 802.11b/g/n 2.4GHz IEEE 802.11a/n/ac 5GHz |
| Signal Rate | Up to 300Mbps2.4GHz UP to 867Mbps 5GHz |
| Frequency Range | 2.4-2.4835GHz; 5.180-5.825GHZ |
| Transmit Power | 20dBm(MAX) |
| Data Transfer Rate | 802.11ac:80MHZ(433Mbps, 867Mbps) 802.11n: 40MHz(300Mbps, 270Mbps, 240Mbps, 180Mbps, 120Mbps, 90Mbps, 60Mbps, 30Mbps) 20MHz (144Mbps, 130Mbps, 115Mbps, 86Mbps, 57Mbps, 43Mbps, 28Mbps, 14Mbps) (Auto- Sense) 802.11g:(54Mbps, 48Mbps, 36Mbps, 24Mbps, 18Mbps, 12Mbps, 11Mbps, 9Mbps, 6Mbps) 802.11b:(11Mbps,9Mbps, 6Mbps, 5.5Mbps, 2Mbps, 1Mbps) |
| Wireless Modes | AP, Client, Multi-SSID |
| Wireless Security | WEP/WPA-PSK/WPA2-PSK Encryption Wireless MAC Filtering FROM EXPERT ZONE |
| <span "="">Hardware | |
| Standards | IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX, IEEE 802.3ab 1000Base-T |
| Interface | 1*10/100/100Mbps Auto MDI/MDIX RJ45 WAN port 3*10/100/100Mbps Auto MDI/MDIX RJ45 LAN port |
| LED Indicators | PER、Internet |
| Buttons | Reset |
| Antenna | 4* external fixed 5dBi antenna |
| Power Supply | DC 12V/1.0A(Output) |
| Dimensions (L x W x H ) | 182mm x 108mm x 25mm |
| <span "="">Software | |
| WAN Type | DHCP, Static IP, PPPoE, L2TP, PPTP |
| Others | Bandwidth Control, Access Control, IPTV, Virtual Server, DMZ, VPN Pass-through, Dynamic DNS, Static Routing, Backup & Restore |
| Certification | FCC, CE, EAC |
| Environment | Operating Temperature: 0℃~40℃ Storage Temperature: -40℃~70℃ Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
| Package | 1* N3D 1* 12V/1.0A Power Adapter 1* Quick Installation Guide (Multilingual |
Mikrotik RB3011UIAS-RM RouterBOARD 10xGigabit Ethernet, USB 3.0, LCD, RB3011
The RB3011 is a new multi port device, our first to be running an ARM architecture CPU for higher performance than ever before. The RB3011 has ten Gigabit ports divided in two switch groups, an SFP cage and for the first time a SuperSpeed full size USB 3.0 port, for adding storage or an external 3G/4G modem.
RB3011UiAS-RM Unit comes with 1U rackmount enclosure, a touchscreen LCD panel, a serial console port and PoE output functionality on the last Ethernet port.
Expert Features
- The RB3011 is a new multi port device, our first to be running an ARM architecture CPU for higher performance than ever before
- The RB3011 has ten Gigabit ports divided in two switch groups, an SFP cage and for the first time a SuperSpeed full size USB 3.0 port, for adding storage or an external 3G/4G modem
- RB3011UiAS-RM Unit comes with 1U rackmount enclosure, a touchscreen LCD panel, a serial console port and PoE output functionality on the last Ethernet port
- Dimensions: 443 x 92 x 44 mm, Size of RAM: 1 GB, Storage size: 128 MB, PoE in: Passive PoE, PoE-out ports: Ether10, PoE out: Passive PoE
- 10/100/1000 Ethernet ports: 10, SFP ports: 1, Number of USB ports: 1, USB slot type: USB 3.0 type A, PCB temperature and Voltage monitor
Specifications
| Details | |
|---|---|
| Product code | RB3011UiAS-RM |
| Architecture | ARM 32bit |
| CPU | IPQ-8064 |
| CPU core count | 2 |
| CPU nominal frequency | 1.4 GHz |
| Switch chip model | QCA8337 |
| Dimensions | 443 x 92 x 44 mm |
| RouterOS license | 5 |
| Operating System | RouterOS |
| Size of RAM | 1 GB |
| Storage size | 128 MB |
| Storage type | NAND |
| MTBF | Approximately 200'000 hours at 25C |
| Tested ambient temperature | -20°C to 70°C |
| IPsec hardware acceleration | Yes |
| Suggested price | $179.00 |
Powering
| Details | |
|---|---|
| Number of DC inputs | 2 (DC jack, PoE-IN) |
| DC jack input Voltage | 10-30 V |
| Max power consumption | 30 W |
| Max power consumption without attachments | 10 W |
| Cooling type | Passive |
| PoE in | Passive PoE |
| PoE in input Voltage | 10-30 V |
TP-Link AC2100 Wireless MU-MIMO VDSL/ADSL Modem Router, Dual-Band, Wi-Fi Speed Up To 2.1 Gbps, OneMeshTM, Versatile Connectivity, 4 x Gigabit Ports +1x 3.0 USB Port, Easy setup (Archer VR2100)
AC2100 Wireless MU-MIMO VDSL/ADSL Modem Router
EXPERT FEATURES
- Super VDSL – The Latest Super VDSL (VDSL2 Profile 35b) tech delivers internet speeds of up to 350 Mbps
- Ultra-Fast Speed –Surpasses the Wi-Fi speed limits of the previous generation, reaching up to 1773 Mbps on 5 GHz and 300 Mbps on 2.4 GHz
- 4×4 MU-MIMO – Simultaneously transfers data to multiple devices for 4x faster performance
- Whole-Home Coverage with OneMeshTM – Co-works with TP-Link OneMesh products to create a flexible and cost-efficient Mesh network
- Lightning-Fast Wired Connection – USB 3.0 port and four Gigabit Ethernet ports run up to 10x faster than the previous generation to unleash your home entertainment
- External Power Supply: 12V/1.5A
EXPERT SPECS
- One Mesh Compatible
- Combined speeds of AC2100 across both 2.4GHz & 5GHZ frequencies
- Supports TP-Link 'One Mesh' technology to deliver a cost effective 'Mesh Network'
- MU-MIMO & Beamforming technologies for stronger, more reliable connections.
- 4 Gigabit ethernet ports for fastest possible wired connections.
- 4 Omni directional high gain antennas.
 |
 |
 |
 |
 |
| Super VDSL Up to 350 Mbps VDSL Access | 1733 Mbps + 300 Mbps AC2100 Dual-Band Wi-Fi | MU-MIMO for Higher Efficiency | Full Gigabit Ports | USB 3.0 Port Rapidly Media Sharing |
TP-LINK Load Balance Broadband Router (TL-R470T+) Up to 4 WAN ports, PPPoE Server, Marshals bandwidth resource
TP-LINK Load Balance Broadband Router TL-R470T+
Expert Features:
- Up to 4 WAN ports equipped with advanced load balance to guarantee maximum bandwidth and backup capabilities
- Provides extensive client account and network management for administrators with supported PPPoE Server
- Marshals bandwidth resource to specific clients based on their unique application environments
- Smaller case for cost-effective solution in the small office or Internet cafes network
Expert Specification:
HARDWARE FEATURES Standards and Protocols: IEEE 802.3, 802.3u, 802.3x, TCP/IP, DHCP, ICMP, NAT, PPPoE, SNTP, HTTP, DDNSInterface: 1 Fixed Ethernet WAN Port 1 Fixed Ethernet LAN Port 3 Changeable Ethernet WAN/LAN Ports
- Network Media: 10BASE-T: UTP category 3, 4, 5 cable (Max 100m), 100BASE-TX: UTP category 5, 5e cable (Max 100m)
- Button: Reset Button
- Power Supply: External 9V/0.6A DC Adapter
- Flash: 16MB
- DRAM: 64MB
- LED: PWR, SYS, WAN, LAN, WAN/LAN
- Dimensions ( W x D x H ): 8.2*5.0*1.0in. (209*126*26mm)
PERFORMANCE
Concurrent Session: 10000BASIC FUNCTIONS
WAN Connection Type: Static/Dynamic IP, PPPoE, PPTP, L2TP, Dual Access, Bigpond Cable DHCP: DHCP Server/Client, DHCP Address Reservation MAC Clone: Modify WAN/LAN MAC Address Switch Setting: Rate Control, Port Configuration, Port VLANADVANCED FUNCTIONS
ACL: IP/MAC/URL/WEB Filtering IGMP: IGMP Proxy/IGMP Snooping Forwarding: Virtual Server, Port Triggering, DMZ Load Balance: Policy Routing, Link Backup Routing: Static Routing Security: FTP/SIP/PPTP/IPsec/H.323 ALG, DoS Defence, Ping of Death, IP/MAC Binding Traffic Control: Bandwidth Control, Session LimitMANAGEMENT
Service: PPPoE Server, E-Bulletin, Dynamic DNS, UPnP Maintenance: Time Setting, Daylight Saving Time, SNMP, Diagnostics, Firmware Upgrade, Factory Defaults/Reboot, Backup/Restore, System Log, Remote Management, StatisticsOTHERS
Certification: CE, FCC, RoHS- Package Contents: TL-R470T+ Power Adapter RJ-45 Ethernet Cable Quick Installation Guide
- System Requirements: Microsoft® Windows® 8, 7,Vista™, XP or MAC® OS, NetWare®, UNIX® or Linux
Environment: Operating Temperature: 0℃~40℃ (32℉~104℉) Storage Temperature: -40℃~70℃ (-40℉~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing
MIKROTIK ETHERNET ROUTER L009UIGS-RM
MIKROTIK Ethernet Router L009UiGS-RM
1x SFP port (2.5G supported) | 8x Gigabit LAN ports (Ether8 has Passive PoE out) | 1x Serial console port (RJ45) | 1x Full size USB 3.0 type A | 2 core CPU | Can be powered in 2 different ways (DC jack, PoE-IN) | RouterOS (Licence level 5)
L009UiGS-RML009 is more than just a router. This product line is up to 4 times faster than RB2011, it has a modern ARM CPU with container support, an innovative enclosure that allows mounting up to four routers in a single 1U space, more RAM, PoE, and 2.5G SFP support. This version comes with 1U rackmount accessories.
The legendary RB2011 product line has provided affordable, flexible, and robust connectivity for over a decade. In fact, it was our very first router with SFP. Finally, it’s time for an upgrade. But don’t worry: we’ve kept and improved all the key elements and features of the beloved RB2011. Even the red color scheme and the appealing price!
Included in the box
- 1x L009UiGS-RM
- 1x 24V 1.5A power supply
- 1x Fastening set K-52
- 1x Rackmount kit K-79
Specifications
Interfaces
RJ45 Ports
(8) 1 Gbps
Number of PoE Ports
1 pcs
PoE Out Standards
Passive PoE
SFP Ports
(1) 1G SFP
USB Ports
(1) USB-A 3.0
System Specification
Chipset
Dual-Core IPQ-5018 800 MHz
RAM
512 MB
Storage Memory
128 MB
Power
Power Method
AC/DC Adapter, 802.3af PoE
Power Supply
External AC/DC Adapter
Supported Input Voltage
24 - 56 V DC
Max Power Consumption
37 W
PSU / POE adapter
24 V DC 1.5 A
Physical Parameters
Dimensions
220 x 125 x 22 mm
Operating Temperature
-40 °C to 70 °C
Package Contains
External Power Supply
Included
Software
MikroTik
RouterOS Level 5
Router NETIS N6 WITH SERVICE NAME AX1800 DUAL BAND Gigabit WIFI 6 WITH 4 ANTENNAS
NETIS N6 WITH SERVICE NAME AX1800 Dual Band Gigabit Wi-Fi 6 Router WITH 4 ANTENNAS
EXPERT FEATURES
- • Works seamlessly with all 802.11a/b/g/n/ac/ax devices
- • Simultaneous 2.4GHz 574Mbps and 5GHz 1201Mbps connections
- • Various WAN connection types in AP Router mode-DHCP, Static IP, PPPoE, L2TP, PPTP, Dual Access (Russia PPPoE/PPTP/L2TP)/3/4G Dongle
- • Multi-SSID providing up to 4 additional separate networks for guests and friends
- • Multiple wireless modes- AP/APR
- • 4* 5dBi high gain antennas
- • Easy wireless security setup at a push of the WPS button
- • Intelligent bandwidth control to manage the bandwidth usage for each computer reasonably
- • Internet Access Control- IP filtering, MAC Filtering, Domain Filtering based on time
- • Quick setup, with built-in multilingual management page
AX1800 Dual Band Gigabit Wi-Fi 6 Router
The Netis router N6 equipped with 802.11AX Wi-Fi 6 technology, will offer you simultaneous dual band connection with 1201Mbps wireless speeds over 5GHz band and 574Mbps over the 2.4GHz band.
Equipped with 880MHz dual core chipset, 256M Bytes DDR3 RAM & 16M Bytes flash, N6 ensures a high performance for different network applications.
OFDMA & MU-MIMO technology allows more devices to do the data transmission at the same moment. With Easy-Mesh wireless technology, you can easily build a high coverage wireless network.
EXPERT SPECS
| Wireless | |
| Standards | IEEE 802.11b/g/n/ac/ax |
| Signal Rate | Up to 574Mbps 2.4GHz UP to 1201Mbps 5GHz |
| Frequency Range | 2.4-2.4835GHz;5.180-5.825GHZ |
| Transmit Power | 20dBm(MAX) |
| Data Transfer Rate | 802.11ax: 2.4GHz, 40MHz(574Mbps) 5GHz, 80MHz 802.11ac:80MHZ(433Mbps, 867Mbps) 802.11n: 40MHz(300Mbps, 270Mbps, 240Mbps, 180Mbps, 120Mbps, 90Mbps, 60Mbps, 30Mbps) 20MHz (144Mbps, 130Mbps, 115Mbps, 86Mbps, 57Mbps, 43Mbps, 28Mbps, 14Mbps) (Auto- Sense) 802.11g:(54Mbps, 48Mbps, 36Mbps, 24Mbps, 18Mbps, 12Mbps, 11Mbps, 9Mbps, 6Mbps) 802.11b:(11Mbps,9Mbps, 6Mbps, 5.5Mbps, 2Mbps, 1Mbps) |
| Wireless Modes | AP, ARP, Multi-SSID |
| Wireless Security | WEP/WPA-PSK/WPA2-PSK Encryption/WPA3 Wireless MAC Filtering |
| Hardware | |
| Standards | IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX |
| Interface | 1*10/100/1000Mbps Auto MDI/MDIX RJ45 WAN port 4*10/100/1000Mbps Auto MDI/MDIX RJ45 LAN port |
| LED Indicators | Power,LAN1-2,WAN,WLAN2.4G,WLAN5G,WPS |
| Buttons | WPS,Reset |
| Antenna | 4* external fixed 5dBi antennas |
| Power Supply | DC 12V/1.5A(Output) |
| Dimensions (L x W x H ) | 236mm*144mm*50 mm (body) |
| Software | |
| WAN Type | DHCP, Static IP, PPPoE, L2TP, PPTP |
| Others | Bandwidth Control, Access Control, IPTV, Virtual Server, DMZ, VPN Pass-through, Dynamic DNS, Static Routing, Backup & Restore |
| Certification | FCC, CE, EAC |
| Environment | Operating Temperature: 0℃~40℃ Storage Temperature: -40℃~70℃ Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
| Package | 1* N6 1* 12V/1.5A Power Adapter 1* Quick Installation Guide (Multilingual) |
TP-Link AX1500 Dual-Band Gigabit Wi-Fi 6 Router, Gigabit Ports, up to 1.5 Gbps, WPA3 Security, Boosted Coverage, Gaming & Streaming, Smart Home (Archer AX12)
TP-Link Dual-Band Gigabit Wi-Fi 6 Router
EXPERT FEATURES
- Wi-Fi 6 Technology: Archer AX12 comes equipped with the latest wireless technology, Wi-Fi 6, for faster speeds, greater capacity and reduced network congestion
- Next-Gen 1.5 Gbps Speeds: Archer AX12 dual-band router reaches even faster speeds up to 1.5 Gbps (1201 Mbps on 5 GHz band and 300 Mbps on 2.4 GHz band)
- Connect More Devices: Wi-Fi 6 technology communicates more data to more devices using revolutionary OFDMA and MU-MIMO technology while simultaneously reducing lag
- More Reliable Coverage: Achieve the strongest, most reliable WiFi coverage with Archer AX12 as it focuses signal strength to your devices using Beamforming technology and four antennas
- Increased Battery Life: Target Wake Time technology reduces your devices' power consumption to extend their battery life
