16 Port Gigabit Unmanaged Network Switch

Expert Features

• High-speed connections: sixteen (16) Gigabit (10/100/1000) Ports for bandwidth-demanding networks
• Plug-and-play installation: easily set up your network without meticulous configuration
• Energy-efficient and: save energy and reduces power to Ports when there's no traffic
• Intelligent power Optimization: optimizes power usage for a port based on the length of cable connected to it
• Solid, metal housing: Durable for Rack mounting and lifetime use
• Fanless design: Quiet operation that's ideal for office s
• Rack mountable: mounts in standard 19" Rack and sits on table tops

DGS-1016C 16 Port Gigabit Unmanaged Network Switch D-Link Ethernet Switch, 16 Port Gigabit Unmanaged Network Internet Hub Desktop Rackmount, Plug N Play , Intelligent power Optimization (DGS-1016C)

5 Port Gigabit Unmanaged Metal Switch F105

Expert Features

• 5 GIGABIT PORTS – High-speed Gigabit ports allow you to connect up to 5 devices for fast file transfers and smooth media streaming
• DURABLE DESIGN - The DGS-105 packs full functionality and Gigabit performance into a sturdy metal design
• QUALITY OF SERVICE - QoS support also enhances your network’s efficiency. QoS cleverly prioritizes network traffic so that time-sensitive data, such as VoIP or surveillance footage, are unaffected even during bursts of high-volume traffic. This allows for an all-around smoother, uninterrupted network experience
• IGMP SNOOPING - Optimizes multicast data streams preventing unnecessary traffic and saving bandwidth
• SILENT OPERATION – With its fanless design, the DGS-105 provides silent operation, perfect for noise-sensitive environments
• ENERGY-EFFICIENT DESIGN - Compliant with IEEE802.3az Energy Efficient Ethernet. Reduces heat generated and allows the switch to run silently while lowering the cost to operate
• AUTO POWER REDUCTION - Auto power reduction when the port has little or no traffic
• CABLE-LENGTH DETECTION - The DGS-F105 can determine the approximate length of cables attached to each port to apply just enough power for data transmission on that link, saving even more power while lowering total cost of ownership (TCO)
• PLUG-AND-PLAY – No configuration or software needed

  DGS-F105 5 Port Gigabit Unmanaged Metal Switch F105 D-Link Ethernet Switch, 5 Port Gigabit 10/100/1000 Mbps Unmanaged Metal Switch Desktop , Plug and Play , LEDs Lights Cables Diagnostics , Compact (DGS-F105), Black

UGREEN-30357

UGREEN 2-PORT USB KVM SWITCH BOX 30357

*Input: VGA portx2;USB 2.0 B Female portx2 *Output: VGA portx1;USB 2.0 A Female portx2 *Control two computers using a single USB keyboard, USB mouse and monitor *Select button for easy switching *Maximum resolution up to 1920*1440 *Plug and Play--no drivers required *Dimension: L136mm x W68mm x H24mm *2pcs USB B to USB A male cable(5ft) are included

1*10/100/1000M Uplink Port switch poe support switch poe reverse and poe switch 8 port

        PRODUCT INTRODUCTION: RPOE switch has intelligent device Power management features solving a major problem of powering  the device for internet service provider. This switch can be powered using remote power from customer using specially designed POE injector or any standard POE injector(24v DC,0.75amp). This eliminates the needs of arranging power at building top (ups not require/No need to pay more money to customer or society).This saves lot of money of ISPs and improves uninterrupted service to the customer. PRODUCT FEATURE: REVERSE POE TECHNOLOGY:7Port 10/100+ 1G Reverse POE switch which has latest generation of fast Ethernet reverse POE switching technology. It contains 7*10/100 base T Reverse Poe ports (RPOE),1*10/100/1000 Base date Uplink Port&12V DC out for Powering ONU. Supports Auto-Negotiation: Each of the ports automatically detect whether connected network devices are running at 10Mbps or 100Mbps (Up-link Port is 1000Mbps) and half-duplex or full-duplex mode, and adjusts the speed and mode accordingly ensuring easy and hassle-free operation. Supports Non-blocking Wire Speed: The switch forwards and receives traffic seamlessly with its Non-blocking wire- speed. Every port of the Switch supports speeds up to 200Mbps(Up-link Port is 2000Mbps)in full-duplex mode simultaneously, providing full wire speed to connected devices and allowing you to run a high speed network smoothly. Cascading support: switches can be cascaded for more users per Building (Up to 1 Main+3 switches ) Port base Isolation u/Hardware VLAN: The feature of Port Isolation is implemented in this unit where in the Ethernet Date of the Uplink Port can be transferred to any of the Downlink ports but the individual Downlink ports cannot communicate with each other. Over voltage Protection: Over voltage Protection is provided on each date port to eliminate damage due to connection of higher voltage(Higher than 24V DC. Up to 30V DC). By mistake if user connect more than 24V POE injector then switch will goes on power off mode and will start working again once this high voltage source is removed. Over current Protection: We have provided over current protection on each port to prevent damage to the switch in case of high current flowing due to any reason. This is provided using Resettable Fuse to facilitate easy maintenance and avoiding frequent change of blown fuse.   PRODUCT APPLICATION: 7*10/100 Base T Reverse POE Ports(RPOE) & 1*10/100/1000 Base T Uplink Port & 12V DC Power out for Powering ONU PRODUCT SPECIFICTAION:

Product	RPOE 7*10/100M+1*1000M 12V2A out
Ethernet Connector	RJ45 Jacks(8 Ports)10/100Base-TX with Auto-MDIX
	1*10/100/1000M Base T Data Uplink Port(port 1)
	7*10/100 Base-Reverse POE Ports(Port 2to 8)Data + Power in
standards	IEEE STD. 802.3 10BASE T 10Mbps,Half/Full Duplex IEEE STD. 802.3U 100BASE-TX,10/100Mbps,Half/Full Duplex IEEE STD.802.3X FLOW CONTROL AND BACK PRESSURE IEEE STD.802.3AZ Energy Efficient Ethernet
Protocols	CSMA/CD
Transmission Method	Store and forward
MAC ADDRESS	Support 8k MAC address
Packet Buffer
Maximum Forwarding Packet Length	Supports 9216-byte jumbo packet length forwarding at wire speed
Filtering/Forwarding Rates	1000Mbps Port – 148800pps 100Mbps Port – 14880pps 10Mbps Port – 14880pps
Network Cable	4-pair UTP/STP Cat 5 cable
LEDs	Link/Activity per Ethernet port Power: On/Off for switch
Power Over Ethernet injector: Power Supply(IN)	Power over Ethernet 24V @ 18W on SPARE pair ( to supply power to the HDV switch as well as a compatible POE device(e.g. CPE)
No. of Ethernet Ports that can Power On the Switch & ONU	Any one /all of the seven Downlink Ports
Power Over Ethernet	Power over Ethernet injector on Four Pair Cable
DC Out	12V/2A DC OUT THROUGH DC jack for powering other Device like ONU
Ethernet Devices that can be powered	Single
CAT-5 Cable Date Lines	Pair 1:Pins 1/2,Pair 2:Pins3/6
CAT-5 Cable Power Lines	+VDC: Pins 4/5,-VDC:Pins 7/8
Power consumption	5 Watt (Poe injector) / 2 Watt (Switch)
Operating Temperature	0℃to 50℃
Storage environment	0℃ to 75℃
Operating Humidity	20% to 95% (non-condensing)
Dimension of Switch	125mm*70mm*25mm
Weight of Switch	0.45KG
