Model |
XP-420B |
Printing Features |
Resolution |
203 DPI |
Printing method |
Direct Thermal |
Max.print speed |
152 mm (6") / s Max. |
Max.print width |
108 mm (4.25”) |
Max.print length |
1778 mm |
Media |
Media type |
Continuous, gap, black mark, fan-fold and punched hole |
Media width |
25.4 mm ~ 115 mm |
Media thickness |
0.06~0.254 mm (2.36~10mil) |
Media core diameter |
25.4 ~ 76.2 mm (1 "~ 3 ") |
Label length |
10 mm ~1778 mm |
Performance Features |
Processor |
32-bit CPU |
Memory |
8MB Flash Memory, 8MB SDRAM, Flash memory can be expanded to Max. 4 GB |
Interface |
Standard version: USB Optional:Lan/WIFI/Bluetooth/TF card |
Sensors |
①Gap sensor
②Cover opening sensor
③Black mark sensor |
Fonts/Graphics/Symbologies |
Internal fonts |
8 alpha-numeric bitmap fonts, Windows fonts are downloadable from software. |
1D bar code |
Code 39, Code 93, Code 128UCC, Code 128 subsets A, B, C, Codabar, Interleaved 2 of 5, EAN-8,EAN-13,EAN-128, UPC-A, UPC-E, EAN and UPC 2(5) digits add-on, MSI, PLESSEY, POSTNET, China POST,GS1 DataBar, Code 11 |
2D bar code |
PDF-417, Maxicode, DataMatrix, QR code, Aztec |
Rotation |
0°、90°、180°、270° |
Emulaion |
TSPL、EPL、ZPL、DPL |
|
Physical Features |
Dimension |
215 mm (L) x 178 mm (W) x 155 mm (H) |
Weight |
1.31 kg |
Reliability |
Warranty |
One year |
Print head life |
30 km or first arrival first |
|
Software |
Driver |
Windows/ Linux/ Mac |
SDK |
Windows/ Android/ iOS |
Power supply |
Input |
AC 110-240V |
Output |
DC 24V 2.5A |
Options |
Factory Options |
①Peeler ②Cutter ③RTC |
Dealer Options |
①External paper roll holder
②Paper roll spindle
③Extension board for external paper roll holder |
Environmental Conditions |
Operation environment |
5 ~ 40°C(41~104°F),Humidity: 25 ~ 85% no condensing |
Storage environment |
-40 ~ 60°C(-40~140°F),Humidity: 10 ~ 90% no condensing |
